Streak plate
Name: Streak plate
Proview: fitter plate(fitter platform)
Next: Cast iron plate (cast iron platform)
Proview: fitter plate(fitter platform)
Next: Cast iron plate (cast iron platform)
Specifications / Features
Warwick crossed plate (platform) use is to check the machine parts flatness, straightness, form and position tolerance was measured at baseline, for components lineation abrasive machining, installation of equipment and other purposes can also be used for scribing of general parts and precision parts, welding technology of grinding machining and measuring.Huawei crossed plate standard requirements:
Warwick crossed plate (platform) material: high strength cast iron ht200-300 face hardness is hb170-240, after two manual processing (artificial annealing 600 degrees - 700 degrees or natural aging 2-3 years) using the product accuracy and stability, wear resistance.
Warwick crossed plate (platform) specifications: 200 * 200-2000 * 4000mm (special specifications can be according to the production and processing of the user customized drawings or both sides agreed.)
The common processing method of the flat plate is scraping the method, the working face of the scribe line can be stored in the lubricating oil and the small ash can be contained in the pit, which improves the reliability and stability of the reference.
Streak plate shape structure and shape: shape structure made of double Wai, Wai and box type. If using a splicing, generally used in the single Wai shape better. The streak plate shape of square, rectangular and circular. Crossed the platform after finishing by hand scraping craft.
